Brand: Brand: Foton Auv Bus
Dimension：7995*2450*3380
Wheelbase(mm)：3800
Front Axle：Chinese front axle 3.6T
Rear axle：Chinese rear axle 7T
download
Whatsapp
| Model | Foton Bus 33+1 |
| Dimension (LxWxH)(mm) | 7995*2450*3380 |
| G.V.W.(kg) | 10150 |
| Seat No. | 33 |
| Wheelbase(mm) | 3800 |
| Min. Ground Clearance(mm) | 180 |
| Max. Gradeability(%) | ≥30 |
| Max. Speed (km/h) | ≥110 |
| Fuel Tank Capacity(L) | 190 |
| Fuel Consumption(L/100km) | ≤18 |
| Engine Model | YC4G180-30 |
| Max Power/Rev. (KW (ps) /rpm) | 132/2300 |
| Gear Box | CA6-75 |
| Clutch | Single plate, dry type clutch |
| Front Axle | Chinese front axle 3.6T |
| Rear axle | Chinese rear axle 7T |
| Suspension System | Air suspension system |
| Steering System | Power steering |
| Tyre | 9R22.5 |
| Air Conditioner | Overhead non-independent air-conditioner (21.000kcal/h) |
| Door and Door Pump | Pneumatic controlled single plate sliding passenger door |
| Body Interior Trimming | Profiled interior trimming |
| Option | Digital clock, driving recorder, launder (extended till under driver window), automatic fire extinguisher for engine compartment, stainless wheel cover. |
Foton Auv Bus-Intercity Bus Series
Suitable for short-distance, tour and scenic routes, these buses are innovative in appearance, powerful, fuel-efficient and able to meet the operational needs of different scenarios in an all-round way.
Foton Auv Bus-Easy Riding and Comfort
Wide body: more space in the cockpit, inside the vehicle, and at the entrance channel, better passability.
Comfortable ride: passenger seats with small rounded corners, increased lumbar support, and USB ports are convenient and practical.
Driving comfort: electronic parking, intelligent color large-screen instrumentation, intelligent temperature-controlled air conditioning, adaptive massage driver’s chair.
Foton Auv Bus-Internet Intelligent Control: Driving from the heart
Cloud Intelligent Control: iTink Intelligent Vehicle Management System, Mobile KTV, more comfortable ride.
Intelligent Cockpit: Multi-function steering wheel, intelligent headlights, sensor wiper, fatigue warning, 360 surround view, keyless start, adaptive massage driver’s chair, driving experience is full of sense.
Foton Auv Bus-Safe Way: All-time escort
Active safety: front and rear dual discs, ABS, ESC, tire pressure monitoring and alarm, multi-channel monitoring, passenger seat belt reminder.
Passive safety: full load-bearing body, high-strength steel, safety door, external sliding window, electromagnetic window striker, flame-retardant materials, safe and reliable.
Power safety: Equipped with fire extinguishing system in the battery compartment, eliminating potential safety hazards.
Foton Auv Bus-Fashionable Appearance Business Aesthetics
Streamlined body: aerodynamic design, dignified shape and smooth lines.
New Business Aesthetics Exterior: Metal chrome plating on the front enclosure matches the FOTON logo, and LED eagle-eye headlamps.
Renewed Multi-color Interior: Various color-matched interior trims, luxurious dashboard/luggage rack.
Foton Auv Bus-Operational Efficiency: Triple Reduction in Consumption
The overall fuel saving rate of Triple Reduction is more than 10%, and the operation cost is lower.
Power consumption reduction: compact structure, light weight, high power, more passenger capacity.
Body consumption reduction: full load bearing + lightweight body; aerodynamic design, windshield tilted back 10°, wind resistance reduced by 15%.
